CAML 50 Ah, 204.8 V / 10 kWh High-Voltage Stackable Lithium Battery
CAML 50 Ah, 204.8 V / 10 kWh High-Voltage Stackable Lithium Battery
The CAML 50 Ah, 204.8 V High-Voltage Lithium Battery from Loom Solar with a high-voltage Battery Management System (BMS) is the ultimate solution for high energy demands, making it perfect for restaurants, hotels, hospitals, and large homes. It provides an impressive lifespan of up to 6000 charge cycles, ensuring long-lasting performance.
Working Principle
The battery gets fully charged in only 2-3 hours due to its fast-charging capabilities. It is easy to maintain, lightweight, and offers a space-saving solution. BMS is compatible with various inverters on the market including Growatt, Goodwe, Deye, Luxpower, and Voltronics featuring transfer-less hybrid technology.
Product Features
- Scalable Modular Design: Supports easy system expansion by connecting multiple battery units in parallel for growing energy demands.
- Easy Installation: Compact, stackable design with standard connectors for quick and clean setup.
- Multiple Communication: Integrated CAN and RS-485 interfaces for inverter and EMS integration with real-time monitoring.
- 20 Years+ Lifespan: Designed to last over 6000 charge cycles at 80% usage with minimal capacity loss.
- Advanced BMS: Monitors temperature, voltage, and current to ensure safety, balanced charging, and optimal performance.
Technical Specifications
| Manufacturer | Loom Solar |
|---|---|
| Model Number | CAML 5051-WM LV |
| Product Name | CAML Wall-Mount Lithium-ion Battery |
| Cell Technology | Lithium Iron Phosphate (LiFePO4) |
| Rated Capacity | 2550 Wh / 51.2 V / 50 Ah |
| Voltage | 51.2 V |
| Charging Cut-off Voltage | 56.16 V |
| Recommend Charge Current | 25 A |
| Max. Continuous Charge / Discharge Current | 0°~15°C: 20 A, 15°~ 45°C: 50 A |
| Peak Current | 100 A |
| Display | Battery SOC Display |
| Communication Port | CAN / RS-485 for Inverter Communication |
| Installation | Wall-Mount / Stackable |
| Maximum Parallel Support | 4 Clusters (3 to 10 units per cluster) |
| Charge / Discharge Temperature | 0°C ~ 55°C |
| Environment | Indoor/Outdoor Under Roof (Avoid Direct Sunlight) |
| Relative Humidity | -20% ~ 60% |
| Cooling | Natural Convection |
| Protection Class | IP65 |
| Grid Connection | Off-grid, Hybrid grid |
| Cycle Life | 6000 Times @ 80% DoD |
| Warranty | 5-year |
| Protection | Smart BMS Protection with Communication |
| Efficiency | 98% |
| Weight | High-Voltage Box: 14 kg | Battery Box: 28 kg |
| Dimensions (mm) | High-Voltage Box: 750 x 210 x 250 | Battery Box: 750 x 210 x 145 |
| Certifications | UN38.3, RoHS, MSDS, CE |
Product Overview
Note: Specifications refer to a single module of 2.5 kWh (2550 Wh). The complete set includes 4 modules, totaling 10.2 kWh capacity.
Ideal for commercial facilities requiring compact high-voltage energy storage with seamless inverter communication and multi-cluster parallel expansion.
